KOWOLUX X-series LED film viewer for NDT X-ray films

The KOWOLUX X viewers are designed for high-end NDT X-ray film evaluation. A durable, economically designed housing made of stainless steel contains latest series of PowerLEDs providing magnificent white light over the entire control range. High luminance and contrast helps inspection personnel to find imperfections and discontinuities easily without vision fatigue. A speed controlled cooling fan reduces irritating noise and a large variety of accessories simplifies handling of films.

KOWOLUX X-series
Viewers with plug-in foot switch (operable with no foot switch connected), an attachable masks system and mounting threads for accessories and fixing.

Housing :
Uniformity factor:
Color temperature:
Brightness control:
Power supply:
Screen glass:
Divergence factor:
Lifetime of LEDs:
Control range:

stainless steel
g > 0.8
5,000 K
2 – with and without footswitch
88 … 264 V / 47 … 63 Hz
thermally cured, translucence 92%
σ‘ > 0.9
> 40,000 h
< 0.5 … 100%

Types:

Article No.:

KOWOLUX X3-series

Viewers for long weld seam X-ray films. Together with KOWOSPOOL spooling device it is perfect for handling of roll format films.

KOWOLUX X3eco

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

80 x 450 mm for films 10×48 cm
200,000 cd/m² – D 4.30
210 W
530 x 220 x 205 mm – 10.1 kg

13 40081

KOWOLUX X3

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

80 x 450 mm for films 10×48 cm
320,000 cd/m² – D 4.50
300 W
530 x 220 x 205 mm – 10.2 kg

13 40080

KOWOLUX X4-series

Viewers for standard weld seam X-ray films. Together with the IRIS lens it is an universal tool for X-ray film evaluation.

KOWOLUX X4eco

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

80 x 225 mm for films 10×24 cm
200,000 cd/m² – D 4.30
110 W
305 x 220 x 205 mm – 6.4 kg

13 40101

KOWOLUX X4

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

80 x 225 mm for films 10×24 cm
320,000 cd/m² – D 4.50
150 W
305 x 220 x 205 mm – 6.6 kg

13 40100

KOWOLUX X5

Viewer especially designed for evaluation of turbine blade X-ray films. Also perfectly suitable for all X-ray films with very high optical density.

KOWOLUX X5

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

110 x 150 mm for films 13×18 cm
630,000 cd/m² – D 4.80
200 W
305 x 220 x 205 mm – 6.7 kg

13 40120

KOWOLUX X7/ X8

Viewer especially designed for evaluation of turbine blade X-ray films. Also perfectly suitable for all X-ray films with very high optical density.

KOWOLUX X7

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

Ø 4 … 75 mm IRIS lens – universal
1,100,000 cd/m² – D 5.00
110 W
305 x 220 x 205 mm – 7.1 kg

13 40140

KOWOLUX X8

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

Ø 6 … 113 mm IRIS lens – universal
650,000 cd/m² – D 4.80
190 W
305 x 220 x 205 mm – 7.5 kg

13 40780

KOWOLUX X6 / 14X17-series

Viewers for large format X-ray films with high optical density. Alternative to the KOWOLUX LX-series viewers.

KOWOLUX X6eco

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

270 x 390 mm for films 30×40 cm
130,000 cd/m² – D 4.10
310 W
530 x 320 x 440 mm – 22.0 kg

13 40601

KOWOLUX X6

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

270 x 390 mm for films 30×40 cm
200,000 cd/m² – D 4.30
450 W
530 x 320 x 440 mm – 25.0 kg

13 40600

KOWOLUX 14x17eco

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

355 x 430 mm for films 14×17 inch
100,000 cd/m² – D 4.00
340 W
530 x 320 x 440 mm – 23.0 kg

13 40651

KOWOLUX 14×17

Viewing area:
Luminance/ Density:
Rated power:
Dimensions/ Weight:

355 x 430 mm for films 14×17 inch
160,000 cd/m² – D 4.20
500 W
530 x 320 x 440 mm – 26.0 kg

13 40650

You can find accessories on the leaflet

leaflet German:
leaflet English: KOWOLUX X
